TEAC HA-P50 Portable Headphone Amplifier With USB DAC

Post by stylelaser.com.my on Tue Jun 26, 2018 1:29 pm

TEAC HA-P50 Portable Headphone Amplifier With USB DAC Brand New. Now Selling At RM1,399. Free Shipping Within West Malaysia.


Please visit [You must be registered and logged in to see this link.] find out more products for sale at very special price...










HA-P50 OVERVIEW

High quality, portable headphone amplifier with built-in 24/96 USB DAC, providing high-resolution 'go anywhere' listening from iPhone, Android and PC/Mac

Main Features

Delivers audiophile Reference sound quality, even when you're outdoors
A portable amplifier that's purpose-designed for high-performance headphones
The HA-P50 is the ideal headphone amplifier for the audiophile on the go. Allows you to take that great Reference 501-grade headphone listening experience outdoors and enjoy it wherever you want to go. Packs a high-performance digital-to-analog adapter and high specification power amplifier circuit into a compact body, to bring out the very best from quality headphones.

Gets high-quality sound from your iPhone or Android (*1) via USB digital input
Digital audio signals stored in your iOS device or Android are extracted digitally via USB and processed through the HA-50's high-performance built-in digital-to-analog converter, with minimal sound degradation and allowing the purest playback quality, with maximum fidelity. The HA-P50 can be used with the free TEAC HR Audio Player app for high-resolution 24bit/96kHz audio playback for iPhones and other iOS-based devices... there's no need to buy a separate adapter (such as the Apple Camera Connection Kit) in order to connect. Also comes with rubber fixing straps for securing it to an iPhone or Android handset, making the HA-P50 very easy to carry around.


*1: AOA2.0 compatible Android phone handset
*2: TEAC HR Audio Player can be downloaded for free from the App store.
Uses a BurrBrown PCM5102 digital-to-analog converter
The built-in BurrBrown PCM5102 digital-to-analog converter is capable of processing digital audio signals up to maximum 24-bit/96kHz resolution



High 160mW + 160mW output gain (at 32Ω load)
Fitted with a 160mW + 160mW high-output power amplifier (at 32Ω load). Lets you drive 600Ω-class headphones at full power.

Low distortion discrete power amp section
Uses a top-flight OPA 1652 operational amplifier to process audio signals with maximum purity. The discrete push-pull circuit achieves a very low distortion rate of 0.001% (at 100mW + 100mW output) which IC-based amplifier headphone circuits cannot match, thanks to meticulous component selection and an absolute insistence on sound quality. Every lesson TEAC has learnt about amplifier sound quality has been applied to the HA-501 in the pursuit of the very best listening experience, one that's wholly uncompromised in a mobile environment.



Dual-setting gain switch for use with high-impedance headphones
Fitted with a high/low gain selector which enables output gain to be matched to the impedance of the headphone being used. An indispensible feature for those who use top quality high-impedance headphones.


Accepts USB input from a PC/Mac
The HA-P50 accepts input from your computer via USB. Capable of high-resolution 24-bit/96kHz sound source playback when used with the TEAC HR Audio Player app (free to download) installed on your Windows PC/Macintosh.

Equipped with both optical digital/analog inputs
This versatile portable audio player employs an optical digital input terminal (*) that can be connected to a home audio system. The HA-P50 creates a high quality digital audio playback environment. With its dual-function AUDIO IN port (*) for analog audio, the HA-P50 takes input from non-digital audio players and passes it through its sophisticated amplifier circuits, letting you enjoy a high quality headphone listening environment wherever you are.

* A combined optical digital input and analog AUDIO IN terminal that self-detects incoming signals.


Compact and robust full aluminum body
Constructed from durable aluminium, the HA-P50's compact, flat body measures just 21.7mm thick, ideal for mobile environments where toughness, small size and lightness are essential. Designed from the outset for mobile use, its compact aluminium volume knob has just the right torque to allow fine volume adjustment. Raised guards on either side prevent accidental volume changes when the HA-50 is being carried in a pocket or bag, as well as protecting headphone plugs from bumps.



Convenient recharging by USB; 8 hour continuous battery life
The HA-P50 has a built-in 2100mAh Li-ion battery, allowing a maximum of 8 hours of continuous battery life (with digital connections) and the included USB-A type DC cable allows recharging from a computer's USB port. A separately sold TASCAM PS-P515U AC adapter allows rapid recharging from wall/mains power, if required. Thanks to its auto power save function, the unit goes into sleep mode after 30 minutes if it has failed to detect a sound signal, or if there's no headphone jack plugged into the headphone port.

Features at-a-glance

  • Digital input from iPhone or Android devices
  • Custom iOS application TEAC HR Audio Player for iOS (free to download) offers 24-bit/96kHz high-resolution audio playback (No Apple Camera Connection Kit needed)
  • High 160mW + 160mW output gain (at 32Ω load)
  • Low 0.001% distortion (at 100mW + 100 mW output)
  • Built-in BurrBrown PCM5102 high-performance D/A converter
  • Discrete output amp section based on a push-pull circuit
  • High quality OP1652 operational amplifier
  • HIGH/LOW gain selector
  • USB input from PC (24-bit/96kHz maximum)
  • Works in conjunction with the TEAC HR Audio Player app for PC/Mac (free to download) to deliver high-resolution audio playback
  • Combination optical digital/AUDIO IN input
  • 3.5mm stereo mini headphone output
  • Slim 21.7mm thick design; sturdy full aluminum body
  • Internal rechargeable 2100mAh Li-ion battery with continuous battery life of approximately 8 hours
  • USB-rechargeable
  • Supplied with rubber fixing straps for securing HA-50 to iPhone or Android handsets
  • Auto power save function



Headphone output
Connector3.5mm (1/8") stereo mini jack
Effective maximum output160mW+160mW(32Ω, 1KHz, 10%, JEITA)
65mW+65mW(300Ω, 1KHz, 10%, JEITA)
35mW+35mW(600Ω, 1KHz, 10%, JEITA)
Compatible impedance8Ω to 600Ω
Analog audio input
Connector3.5mm (1/8") stereo mini jack (combination optical digital input; automatic detection)
Digital audio inputs
USB 1
ConnectorUSB Micro B-type(USB2.0)
Compatible productPCs (Windows, Macintosh) with the compatible product TEAC HR Audio Player installed
Compatible Formats(PCM)96kHz/24bit
USB 2
ConnectorUSB A-type, (USB2.0)
Compatible productsiPhone 5s, iPhone 5c, iPhone 5,
iPad Air, iPad (4th generation) iPad mini with Retina display,
iPad mini. iPod touch (5th generation),
iPod nano (7th generation),
Android (AOA2.0 compatible Android phone handset)
Compatible Formats
iOS96kHz/24bit (when using TEAC HR Audio Player for iOS)
Android44.1kHz/16bit (AOA2.0 compatible Android phone handset)
OPTICAL
Connectoroptical mini-jack (combination AUDIO IN port; automatic signal detection)
DAC Section
D/A converterBurrBrown PCM5102
BatteryBuilt-in rechargeable Li-ion battery
Battery capacity2,100mAh
Recharging methodUSB (via USB-A DC recharging cable)
Continuous battery lifeApproximately 8 hours (when using digital input)
Dimensions64(W)×21.7(H)×112(D)mm (excluding protruding guards)
2.5"(W)×0.85"(H)×4.4"(D) (excluding protruding guards)
Weight210g / 7.4oz
Included accessoriesElectric recharging cable included (DC plug – USB A plug) Computer connection cable (USB micro B plug – USB A plug) Rubber fixing straps for fastening×2





Audio Performance
Frequency response10Hz to 100kHz(when using AUDIO IN input)
Overall distortion0.001%(32Ω, 1kHz, 100mW + 100mW, JEITA)









System requirements (for Mobile)
iOS
Compatible OSiOS 6
iOS 7
iOS 8
iOS 9
iOS 10
Android
Compatible OSAndroid 6.0 Marshmallow
Android 7.0 Nougat









System requirements (for Desktop)
Windows
Compatible OSWindows 7
Windows 8
Windows 8.1
Windows 10
Macintosh
Compatible OSOS X Lion (10.7)
OS X Mountain Lion (10.Cool
OS X Mavericks (10.9)
OS X Yosemite (10.10)
OS X El Capitan (10.11)
macOS Sierra (10.12)
Interested please feel free to contact:


Peter  012-2536225

Fong   016-3098668



Business hour:

MONDAY - 10AM-7PM

TUESDAY - 10AM-7PM

WEDNESDAY - CLOSED(PASAR MALAM)

THURSDAY - 10AM-7PM

FRIDAY - 10AM-7PM

SATURDAY - 10AM-7PM

SUNDAY - 1PM-6PM

PUBLIC HOLIDAY - 1PM-6PM

Style Online Store 24Hous



location:

STYLE LASER AUDIO SDN BHD

No.148, Jalan Cerdas, Taman

Connaught, Cheras 56000 Kuala Lumpur

( NEXT TO ALLIANCE BANK )




We buy in your old items in CASH!!

Got something keep at home but seldom use or planning to upgrade?

Items that we buy:

BRANDED led tv

amplifier

speaker

cd player



Please Whatsapp the item photo to me and get the price immediately, once confirmed the deal, we will pick up your item from you and pay you in cash.


Please visit [You must be registered and logged in to see this link.] find out more products for sale at very special price..



Thanks for viewing.
